Low-Pro Flatdeck With 7K Singles (LS)
Designed for the needs of contractors, farmers, and equipment haulers, the Low-Pro Flatdeck With 7K Singles Trailer (LS) delivers maximum load surface and strength without sacrificing reliability.
Featuring a 15,680 lbs G.V.W.R., the LS is built for the heavy-duty hauling. From its lifelong LED lights, treated floor, dual jacks, and gooseneck coupler, it’s ready to help you chase your dreams—no matter what you’re hauling.
What Drives You, Drives Us
Trailer Specifications
102" Deck Width
20' – 40' Deck Lengths
15,680 lbs GVWR
11,120—17,240 lbs Load Capacity
Model | Pull Type | GVWR | Empty Weight | Deck Length | Deck Width |
---|---|---|---|---|---|
LS (20') | Gooseneck | 15680 lbs | 4560 lbs | 20 | 102" |
LS (22') | Gooseneck | 15680 lbs | 4775 lbs | 22 | 102" |
LS (24') | Gooseneck | 15680 lbs | 4991 lbs | 24 | 102" |
LS (26') | Gooseneck | 15680 lbs | 5222 lbs | 26 | 102" |
LS (28') | Gooseneck | 15680 lbs | 5440 lbs | 28 | 102" |
LS (30') | Gooseneck | 15680 lbs | 5660 lbs | 30 | 102" |
LS (32') | Gooseneck | 15680 lbs | 5878 lbs | 32 | 102" |
LS (34') | Gooseneck | 15680 lbs | 6099 lbs | 34 | 102" |
LS (36') | Gooseneck | 15680 lbs | 6324 lbs | 36 | 102" |
LS (38') | Gooseneck | 15680 lbs | 6540 lbs | 38 | 102" |
LS (40') | Gooseneck | 15680 lbs | 6760 lbs | 40 | 102" |
Standard Feature | Click + for Options |
---|---|
Axles |
[72BS] (2) 7,000# Electric / Spring
Available Options |
Suspension | 6-Leaf Slipper Spring Suspension |
Tongue | 12" x 14 lb. I-beam Tongue |
Coupler |
[R] GN 2-5/16" Round (25,000 lb.) w/ Toolbox
Available Options |
Safety Chains | 3/8" Grade 70 Safety Chain w/Clevis hook (2 each) |
Jack |
Spring Loaded Drop Leg Jack (12,000 lb.)
Available Options |
Frame |
12" x 14 lb. I-Beam Main Frame (Pierced)
Available Options |
Cross-Members | 3" Channel Crossmembers on 16" Centers |
Floor |
2" Treated Pine Lumber Deck
Available Options |
Fenders | Diamond Plate Low-Pro Fenders |
Ramps |
8' Slide-In Channel Ramps
Available Options |
Stake Pockets | Stake Pockets along both sides (Quantity depends on length) |
Lights |
Available Options |
Wiring | All-Weather Wiring Harness (7-way RV) |
Tires | ST235/80R16 Radial Tires 10 ply (3,520 lbs.) |
Paint Color |
[K] Black Powder Coat
Available Options |
Rubrail | 2" Rubrail |
Tie-Downs |
Available Options |
Breakaway System | Electric Breakaway Kit w/ Charger |
Battery |
Available Options |
Steps | Monster Steps on Both Sides |
Storage |
Available Options |
Cargo Winch |
Available Options |
Pipe Chain Spools | Pipe Spools |
Tail |
[S] Straight Deck w/ 8' Slide-in Ramps
Available Options |
Other Options |
Available Options |
WARNING: This product can expose you to chemicals including Arsenic (inorganic arsenic compounds) which is known to the State of California to cause cancer and Lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
