Gooseneck Deckovers /

Low-Pro Flatdeck With 7K Singles (LS)

The Low-Pro Flatdeck With 7K Singles Gooseneck Trailer (LS)

Designed for the needs of contractors, farmers, and equipment haulers, the Low-Pro Flatdeck With 7K Singles Trailer (LS) delivers maximum load surface and strength without sacrificing reliability.

Featuring a 15,680 lbs G.V.W.R., the LS is built for the heavy-duty hauling. From its lifelong LED lights, treated floor, dual jacks, and gooseneck coupler, it’s ready to help you chase your dreams—no matter what you’re hauling.

What Drives You, Drives Us

Trailer Specifications

102" Deck Width

20' – 40' Deck Lengths

15,680 lbs GVWR

11,120—17,240 lbs Load Capacity

Model Pull Type GVWR Empty Weight Deck Length Deck Width
LS (20') Gooseneck 15680 lbs 4560 lbs 20 102"
LS (22') Gooseneck 15680 lbs 4775 lbs 22 102"
LS (24') Gooseneck 15680 lbs 4991 lbs 24 102"
LS (26') Gooseneck 15680 lbs 5222 lbs 26 102"
LS (28') Gooseneck 15680 lbs 5440 lbs 28 102"
LS (30') Gooseneck 15680 lbs 5660 lbs 30 102"
LS (32') Gooseneck 15680 lbs 5878 lbs 32 102"
LS (34') Gooseneck 15680 lbs 6099 lbs 34 102"
LS (36') Gooseneck 15680 lbs 6324 lbs 36 102"
LS (38') Gooseneck 15680 lbs 6540 lbs 38 102"
LS (40') Gooseneck 15680 lbs 6760 lbs 40 102"

Standard Feature Click + for Options
Axles [72BS] (2) 7,000# Electric / Spring

Available Options

[92BS] (2) 7,000# w/14 Ply LR-G Tires Electric / Spring

Suspension 6-Leaf Slipper Spring Suspension
Tongue 12" x 14 lb. I-beam Tongue
Coupler [R] GN 2-5/16" Round (25,000 lb.) w/ Toolbox

Available Options

[B] BP 2-5/16" Adjustable Rigid Mount (25,000 lb.) with Toolbox [P] 3" Pintle Eye - Face-Mount (36,000 lb.) w/ Toolbox [Q] GN 2-5/16" Square (30,000 lb.) w/ Toolbox [R] GN 2-5/16" Round (25,000 lb.) w/ Toolbox [S] GN 2-5/16" Square (25,000 lb.) w/ Toolbox

Safety Chains 3/8" Grade 70 Safety Chain w/Clevis hook (2 each)
Jack Spring Loaded Drop Leg Jack (12,000 lb.)

Available Options

[-JA01] Dual HD 25k Jost Jacks [-JA02] 2-Speed Gooseneck Jack Upgrade (12,000 lb.) [-JA06] 2 Hydraulic Jacks (GN Upgrade) [-JA08] Dual 10k Jacks at Rear of Deck

Frame 12" x 14 lb. I-Beam Main Frame (Pierced)

Available Options

[-FR19] 19 lb. I-Beam Main Frame, Riser & Neck [-FR22] 22 lb. I-Beam Main Frame [-CM12] 12" OC Crossmembers [-FRFB] Frame Bridging [-FRTG] TwistGuard™ (Under 30')

Cross-Members 3" Channel Crossmembers on 16" Centers
Floor 2" Treated Pine Lumber Deck

Available Options

[-BWFT] Blackwood Pro Full Deck (Tail Only) [-FLWD] Add Wood to Dovetail [-BWOD] Blackwood Pro Outer Deck [-BWFD] Blackwood Pro Full Deck [-FLRO] Rough Oak Floor [-FLNF] No Flooring [-SF01] 11ga (1/8") DP Steel Floor w/ Flushmount D-Rings & 12" OC [-SF04] 3/16" DP Steel Floor w/ Flushmount D-Rings & 12" OC [-SF05] ¼" DP Steel Floor w/ Flushmount D-Rings & 12" OC

Fenders Diamond Plate Low-Pro Fenders
Ramps 8' Slide-In Channel Ramps

Available Options

[-NRNP] No Ramps No Ramp Pockets

Stake Pockets Stake Pockets along both sides (Quantity depends on length)
Lights

Available Options

[-LT10] GN Light Bar w/ 4 Lights (GN Only) [-SL02] 2 Extra Side Marker 3/4" Bullet Lights, 1 Per Side [-LT11] Auxiliary Work Light Package (GN Only)

Wiring All-Weather Wiring Harness (7-way RV)
Tires ST235/80R16 Radial Tires 10 ply (3,520 lbs.)
Paint Color [K] Black Powder Coat

Available Options

View Color Options

[K] Black Powder Coat [0] Primer + Black Powder Coat (Texas Only) [1] Primer + Red Powder Coat (Texas Only) [3] Primer + White Powder Coat (Texas Only) [5] Primer + Tractor Orange Powder Coat (Texas Only) [6] Primer + Grey Powder Coat (Texas Only) [8] Primer + Desert Tan Powder Coat (Texas Only) [P] Primer Only [Z] No Paint No Primer

Rubrail 2" Rubrail
Tie-Downs

Available Options

[-RT01] 1 Pair Weld-On Ratchets [-RTST] 4" Ratchets every 4ft w/ Slide Track [-2RST] 4" Ratchets every 4ft w/ Slide Track (BOTH SIDES) [-UFTD] Under Frame Tie Down Flat [-UFT2] Under Frame Tie Down Flat on Both Sides [-DR01] 1 Extra Pair D-Rings [-DR21] 1 Extra Pair Flushmount D-Rings

Breakaway System Electric Breakaway Kit w/ Charger
Battery

Available Options

[-BYBC] 1 Extra Battery Charger 12V [-BYSC] Solar Battery Charger

Steps Monster Steps on Both Sides
Storage

Available Options

[-GNCH] GN Lockable Chain Holder [-SB02] 1 Side-mount Toolbox 45"x14" [-SB03] 1 Side-mount Toolbox 72"x14" [-TB02] Top Riser Toolbox

Cargo Winch

Available Options

[-WN02] HD GN Winch Plate [-WN03] Winch Plate w/ Welded Receiver Hitch [-WN04] Gooseneck Winch Plate [-WN12] Winch 12K w/Plate & Battery [-WN18] Winch 17.5K w/HD Plate & Battery [-WN95] Winch 9.5k w/ Plate & Battery [-WNRR] Roller on Rear of Deck for Winch Cable

Pipe Chain Spools Pipe Spools
Tail [S] Straight Deck w/ 8' Slide-in Ramps

Available Options

[F] 5' Dovetail w/ 2 Flip-over Ramps [W] 5' Dovetail w/ 2 Flip-over Monster Ramps [Z] 5' Dovetail w/ Power Tail (Pat. Pend. TX Only)

Other Options

Available Options

[-DON1] Removable Deck on the Neck (102" Wide 96" Long) [-DON3] Rem Deck on Neck w/SlideTrk & 2 Ratchets(102"x96") [-MF01] Mud Flaps Single Wheel Deckover [-RASA] Ramp Support Arms [-RAWR] Hinged Side Mount Wood Rack

WARNING: This product can expose you to chemicals including Arsenic (inorganic arsenic compounds) which is known to the State of California to cause cancer and Lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
