83" Pro-Lift Dump (DT)

83" Pro-Lift Dump Trailer (DT)

Does getting a job done—especially big ones that are difficult and challenging—drive you? Then the 83" Pro-Lift Dump (DT) is for you

For professionals in construction, landscaping, and even waste management, the DT is engineered and designed to haul and transport heavy-duty, bulky cargo and debris. And it gets the job done with its first-rate 12-ton front-mounted telescopic cylinder and adaptable 2-way gate system, making unloading and loading an easy task instead of a back-breaking one. We know you’re driven; it’s time to get a trailer that has the same drive as you.

What Drives You, Drives Us™

Trailer Specifications

83" Deck Width

14' – 16' Deck Lengths

14,000 lbs GVWR

9,750—11,920 lbs Load Capacity

Standard Feature Click + for Options
Axles [72BS] (2) 7,000# Electric / Spring

Available Options

[72BD] (2) 7,000# Electric / Drop Axle [82BS] (2) 8,000# Oil Bath w/14 Ply LR-G Tires Electric / Spring [92BS] (2) 7,000# w/14 Ply LR-G Tires Electric / Spring [92BD] (2) 7,000# w/14 Ply LR-G Tires Electric / Drop Axle [K2BS] (2) 8,000# Oil Bath w/215/75R17.5 LR-H Singles Electric / Spring [Y2BS] (2) 7,000# w/215/75R17.5 LR-H Singles Electric / Spring

Suspension 6-Leaf Slipper Spring Suspension
Tongue 8" x 13 lb. I-beam Tongue
Coupler [J] BP 2-5/16" Adjustable- Demco EZ-Latch

Available Options

[A] BP 2-5/16" Adjustable (14,000 lb.) [P] 3" Pintle Eye - Channel-Mount (20,000 lb.) [T] BP 2-5/16" Adjustable Coupler (20,000 lb.) w/HD 6-Hole Channel Bracket

Jack Drop Leg Jack (12,000 lb.)

Available Options

[-JA02] 2-Speed Gooseneck Jack Upgrade (12,000 lb.) [-JA04] Upgrade to Single 10k Jack (BP Only) [-JA17] Single 2-speed Jack (12,000 lb.) (BP Only)

Frame 8" x 13 lb. I-Beam Main Frame

Available Options

[-CM12] 12" OC Crossmembers

Cross-Members 3" Channel Crossmembers on 16" Centers
Floor 7ga. Steel Bed

Available Options

[-SF06] 7ga Smooth Plate Steel Floor w/ 4 D-Rings

Fenders 1/8" Treadplate Steel Fenders
Ramps 6' 6" Slide-In Channel Ramps
Stake Pockets Stake Pockets along both sides (Quantity depends on length)
Wiring All-Weather Wiring Harness (7-way RV)
Tires ST235/80R16 Radial Tires 10 ply (3,520 lbs.)
Paint Color [K] Black Powder Coat

Available Options

View Color Options

[K] Black Powder Coat [0] Primer + Black Powder Coat (Texas Only) [1] Primer + Red Powder Coat (Texas Only) [3] Primer + White Powder Coat (Texas Only) [5] Primer + Tractor Orange Powder Coat (Texas Only) [6] Primer + Grey Powder Coat (Texas Only) [8] Primer + Desert Tan Powder Coat (Texas Only) [P] Primer Only [Z] No Paint No Primer

Tie-Downs (4) D-Rings (Welded inside the Box)

Available Options

[-DR01] 1 Extra Pair D-Rings

Breakaway System Electric Breakaway System w/ Charger
Battery 12V Deep Cycle Battery

Available Options

[-BYEB] 1 Extra Battery [-BYSC] Solar Battery Charger

Charging System 110V Integrated Trickle Charger
Hydraulics Hydraulic - Power Up / Gravity Down
Lift Type 3-Stage Telescopic Cylinder
Sides 24" 10ga. UniWall Steel Sides

Available Options

[-SE24] 24" Side Extensions (Solid) [-SW03] 3ft Tall Sides [-SW04] 4ft Tall Sides

Steps Treadplate Step (Both Sides)
Storage

Available Options

[-TB02] Top Riser Toolbox

Tarp Roll-up Tarp Kit (Pull Bar) 7' x 20'
Cargo Winch

Available Options

[-WN01] Plate for Winch (BP Only) [-WN02] HD GN Winch Plate [-WN04] Gooseneck Winch Plate [-WN12] Winch 12K w/Plate & Battery

Tail [T] Split / Spreader Gate
Dump Gate 2-Way Gate (Barn Doors & Spreader Gate)
Lift Cylinder 120" Cylinder on 14' length & 144" Cylinder on 16' length
Other Options

Available Options

[-DON1] Removable Deck on the Neck (102" Wide 96" Long) [-GV09] 9,900 G.V.W.R. [-GV16] 16,000 GVWR Must have 16k coupler/7k axles min. [-RS01] Rear Support Stands

Model Pull Type GVWR Empty Weight Deck Length Deck Width Tongue Length
DT (14') Bumperpull 14000 lbs 4080 lbs 14 83" 4' 10" (58")
DT (16') Bumperpull 14000 lbs 4250 lbs 16 83" 4' 10" (58")

WARNING: This product can expose you to chemicals including Arsenic (inorganic arsenic compounds) which is known to the State of California to cause cancer and Lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Similar Products

When your work involves hauling heavy materials every day, productivity depends on having a dump trailer that unloads quickly, carries serious payload, and stands up to years of demanding use. The PJ DT 83" Telescopic Dump Trailer is engineered for contractors, landscapers, excavation companies, municipalities, utility contractors, farmers, and commercial fleets that need dependable hydraulic dumping performance in a rugged low-profile trailer.

Built around a heavy-duty steel frame and powered by PJ's advanced 5-stage front-mounted telescopic hydraulic cylinder, the DT delivers fast, smooth dumping performance while maintaining a lower profile for easier equipment loading. Whether you're hauling gravel, dirt, rock, demolition debris, mulch, asphalt, or compact equipment, the PJ DT is designed to work harder so your crew can accomplish more every day. The trailer features an 83-inch bed width, 14-foot bed length, a 15,400-pound GVWR, and approximately 11,420 pounds of payload capacity, depending on configuration.

A professional dump trailer should do more than move loose material.

The PJ DT is designed to serve as both a high-capacity dump trailer and a versatile equipment hauler, allowing contractors to reduce the number of trailers they need on the job.

Common hauling applications include:

For many contractors, that flexibility means one trailer can handle multiple jobs throughout the workweek while reducing equipment costs.

The defining feature of the PJ DT is its 5-stage front-mounted telescopic hydraulic cylinder.

Unlike many traditional scissor-hoist dump trailers, a telescopic cylinder delivers lifting force from the front of the trailer, creating a smoother dumping motion while allowing the trailer to achieve an impressive 45-degree dump angle. This steeper angle helps materials slide out more completely, reducing the need for manual cleanup and making sticky materials easier to unload.

For contractors hauling wet soil, clay, asphalt, or demolition debris, faster and cleaner unloading means more productive workdays.

Every component of the PJ DT is engineered for demanding commercial environments.

A robust 8-inch I-beam main frame, closely spaced channel crossmembers, and a heavy-duty 7-gauge steel bed create exceptional structural strength while resisting twisting and flex under heavy loads. Reinforced treadplate fenders, premium suspension components, and commercial-grade running gear are designed to withstand years of jobsite abuse while maintaining dependable performance.

Additional heavy-duty features include:

These components work together to reduce downtime while maximizing durability over the life of the trailer.

Although engineered as a professional dump trailer, the PJ DT also performs exceptionally well as a compact equipment trailer.

Its low-profile design and slide-in channel ramps make loading machinery simple while reducing loading angles for improved safety.

The DT is well suited for transporting:

For contractors who routinely move equipment before hauling material away from the jobsite, the PJ DT provides outstanding versatility in a single trailer.

The PJ DT has become a popular choice because it serves so many industries.

It's ideal for:

Whether you're delivering aggregate in the morning, hauling debris after lunch, or transporting equipment to tomorrow's project, the DT is built to handle demanding commercial workloads.

Every feature on the PJ DT is designed to help operators work more efficiently.

The 45-degree dump angle allows material to unload quickly, while the front-mounted telescopic cylinder provides smooth lifting performance throughout the dump cycle. A lockable toolbox protects the hydraulic pump and battery from weather and theft, while integrated welded D-rings simplify securing equipment during transport.

The trailer also features a split/spreader gate, slide-in ramps, durable powder coat finish, and a deep-cycle battery with charging system to keep the hydraulic system operating reliably day after day.

Whether you're hauling gravel to a construction site or removing demolition debris at the end of a project, your trailer needs to maximize productivity while minimizing downtime.

The PJ DT's combination of commercial-grade construction, advanced telescopic hydraulics, and versatile equipment-hauling capability makes it an excellent investment for businesses that depend on reliable hauling equipment.

Instead of owning separate trailers for materials and compact equipment, many operators choose the DT because it performs both jobs exceptionally well.

The PJ DT combines innovative hydraulic technology with heavy-duty commercial construction to create one of the most capable dump trailers in its class.

Highlights include:

Whether you're hauling aggregate, demolition debris, landscaping materials, compact equipment, or construction supplies, the PJ DT 83" Telescopic Dump Trailer delivers the strength, hydraulic performance, and long-term durability professionals demand. Designed for maximum productivity and engineered to withstand years of hard work, it's ready for whatever the next job requires.
